Cousins of Emneth Ltd
V FormTM Plus - Medium Duty
Effective configuration of offset tines is proven much more efficient than standard single beam alternatives. The leading tine disturbs the soil for the following tines, achieving a complete movement of soil across the working width of the frame, intensifying the cultivation. The rear attachment disperses the suction from the tines into useful energy for crushing, levelling and depth control. The result is elimination of large clods, good moisture retention and a level surface finish.
All V-Form models can be fitted with Cousins original level lift subsoil legs or ‘Quickfoot’ legs with 1 bolt fixing for minimum down time. A choice of rear attachments is available (please consult Cousins).
Features
- Cat 2 Linkage
- 150 x 100 (6” x 4″) Toolbar
- Shear bolt Protection
- 150 x 25mm (6” x 1”) Legs
- Toothed Packer, Crumbler, Coil
- Max working depth 350mm (14″)
Rear attachments (choose from)
- Crumbler Barrel
- Toothed Packer
- Solid Coil
Options
- 450mm (18″) depth wheels
- No rear attachment
- Disc Assemblies
| C/W Toothed Packer | C/W Crumbler | C/W Solid Coil | C/W Razor Rings | C/W Leg Zone Press | ||
|---|---|---|---|---|---|---|
| 610mm (24") | 450mm (18") | 610mm (24") | ||||
| Working Width | Tines | kg | kg | kg | kg | kg |
| 2.5m | 3 | 1083 | 887 | 1116 | 1186 | |
| 5 | 1226 | 1030 | 1259 | 1329 | ||
| 3m | 3 | 1220 | 982 | 1320 | 1323 | |
| 5 | 1363 | 1124 | 1463 | 1466 | 1330 | |
| 3.5m | 6 | 1500 | 1218 | 1525 | 1603 | |
| 7 | 1643 | 1360 | 1667 | 1745 | ||
For Micro Wing option available at a reduced cost per tine.
For Double Tine option available for an additional cost per tine.
Extra leg for above machine c/w bracket available
Disc assembly per leg available
18” depth Wheels (pair) available
All prices are recommended retail prices (ex-works) exclusive of VAT. Carriage will be charged on orders dispatched. All prices are subject to change.
